CONCEALED FASTENER DETAILS

NO INSULATION

Click on the blue dots on the map to scroll down to the descriptions below to get a close up of each area shown on the map. Or, download the entire package details right here:

A - Section - Horizontal Joint

Section showing horizontal joint at NorthClad CF concealed fastener panel system. Application for insulation interior of sheathing (No external insulation).

B - Plan - Vertical Joint

Plan section showing vertical joint at NorthClad CF Series concealed fastener panel system. Application for insulation interior of sheathing (No external insulation).

C - Section - Base Of Wall

Section showing base of wall at concealed fastener panels without rigid insulation. Application for insulation interior of sheathing (No external insulation).

D - Section - Parapet Coping

Section showing parapet coping at NorthClad CF panel system without exterior insulation. Application for insulation interior of sheathing (No external insulation).

G1 - Plan - Outside Corner

Outside corner condition detail at NorthClad CF without exterior insulation. Application for insulation interior of sheathing (No external insulation).

H1 - Plan - Inside Corner

Plan section showing inside corner condition at concealed fastener panels without exterior insulation. Application for insulation interior of sheathing (No external insulation).

J1 - Section - Window Sill

Section showing window sill condition at NorthClad CF concealed fastener panels without exterior insulation. Application for insulation interior of sheathing (No external insulation).

J2 - Section - Louver Sill

Section showing louver sill at NorthClad CF system.
Application for insulation interior of sheathing (No external insulation).

K1 - Section - Window Head

Section detail showing window head flashing condition at NorthClad CF. Application for insulation interior of sheathing (No external insulation).

K2 - Section - Louver Head

Section detail showing louver head condition at NorthClad CF series panel system. Application for insulation interior of sheathing (No external insulation).

K3 - Section - Door Head

Section detail showing door head flashing at NorthClad CF. Application for insulation interior of sheathing (No external insulation).

M1 - Plan - Window At Right Jamb

Plan section showing right window jamb condition at NorthClad CF panel system. Application for insulation interior of sheathing (No external insulation).

M2 - Plan - Louver At Right Jamb

Plan detail showing louver condition at right jamb. Application for insulation interior of sheathing (No external insulation).

M3 - Plan - Right Door Jamb

Plan detail showing right door jamb flashing condition at concealed fastener panel system. Application for insulation interior of sheathing (No external insulation).

N1 - Plan - Window At Left Jamb

Plan section showing window flashing at left jamb for NorthClad CF system without insulation exterior of the building envelope. Application for insulation interior of sheathing (No external insulation).

N2 - Plan - Louver At Left Jamb

Plan section showing louver system left jamb at NorthClad CF series panels. Application for insulation interior of sheathing (No external insulation).

N3 - Plan - Door At Left Jamb

Plan detail showing left door jamb condition at NorthClad CF panels. Application for insulation interior of sheathing (No external insulation).
